KVH – Freestanding kiosk ventilation system (UL)

Overview

• Halton’s Capture Jet™ technology, allows effective capture and containment of grease and other effluents.
• Standard delivery includes High efficiency grease filtration using Halton’s KSA multi-cyclone filters – up to 95% removal of particles at a size of 8 microns or above – *UL and **NSF classified.
• Modular construction simplifies design and installation.
• Manufactured from polished stainless steel, welded liquid tight design.
• Carbon filter to minimize odor.
• No ESP (Electrostatic precipitator) required.
• Low maintenance.
• Listed to UL710B standard.
• Surpasses stringent EPA 202 requirements for grease removal in ductless systems.
• Low noise levels.
• Self-contained fire protection system provides total coverage and allows equipment changes without a change to the fire protection nozzle location.
• The unit construction allows a 0” clearance to combustibles on the back and left side, and a 3” clearance on the right side.
• Allows 100% recirculation of exhaust air to the space.

Specification

The KVH hood has been specially developed to clean the effluent emmitted by the cooking process. The grease extraction system consists of a KSA grease extraction filter and carbon filter. The air is then exhausted by into the kitchen space.
